MPD scissor lift manlift series adopts pure hydraulic drive, the working height covers 16 m the maximum load is up to 300 kg, using the battery as the power, energy saving, and environmental protection, zero-emission, noiseless, suitable for indoor flat ground and high-altitude operation environment with high environmental requirements.
Aerial Work Platform
Scissor Lift
MPD.1613
Technical Documents
TECHNICAL SPECIFICATIONS
MPD.1613
Dimensions
A- Working Height
15,70 M
B - Platform Height - Lifted
13,70 M
D - Platform Height - Lowered
1,67 M
D+C - Closed Height - Stowed Handrails
2,82 M
Closed Height (Handrails Folded)
2,32 M
C - Handrails Height
1,10 M
E X F - Platform Dimensions
2,64 x 1,30 M
K - Extension Deck
0,90 M
G - Total Width
1,40 M
L - Total Length
2,87 M
J- Wheelbase
2,26 M
Ground Clearance -Center
10 CM
Ground Clearance Pothole Deployed
25 MM
Productivity
Lift Capacity
350 KG
Extension Deck Capacity
100 KG
Maximum Occupancy
2
Rise / Lower Time
75 / 80 SEC
Weight
3700 KG
Gradeability
20 %
Drive Speed ( Rised / Stowed )
0,8 / 2,4 KM
Tyres - Solid non-marking
15x5
Turning Radius
2500 MM
Drive Type
Front Wheel-Hydraulic
Brake
Rear Wheel - Hydraulic
Power
Machine Type
Hydraulic
Power Source
24 V Battery
Battery
4x6V 242 Ah
Charger
24V 30 Ah
